Features and benefits
- Coloured 4.3“ TFT display screen (SYS, DIA, MAP, pulse, SpO2, Temp, plethysmogram)
- Temperature alternatively with infrared technology for the ear measurement or with Filac™ 3000 for the oral/rectal measurement including probe dispenser
- Memory function for measurement readings and infrared interface for infrared printer
- Shock resistant
- NIBP (non-invasive blood pressure) modes for adults and neonates
- Washable and disinfectable cuffs with coiled tube, extendible up to 2 m. Including cuffs for adults and large adults
- SpO2 sensors with a cable length of 1.2 m (47.2 in) or optional 2.40 m (94.5 in)
- Optional with PEARL measuring technology for the use with critical patients (e. g. neonates)
- Easy handling via membrane keyboard (disinfectable) and self-explanatory menu
- Practical storage facilities for accessories (cuffs, sensors, cable, probe covers)
- Efficient and lightweight rechargeable Li-ion battery pack (approx. 250 measurements)
- Portable version or mounted on a stable and smooth running mobile stand with large basket and optional printer holder
- Independent protection system against excess pressures according to EN1060-3
Product details
ri-vital
Measurement accuracy
According to EN1060-4:2005
Deviation from average value
< 5 mmHg
Battery
ri-accu® L 7.4 Li-Ion battery
Operation time
Approx. 250 measurements NIBP and SpO2
Charging time
8 hours
Mains adapter
AC/DC adapter plug with connector according IEC60320-C13, 100 V – 240V
Basket
250 mm / 9.84 in (L) x 150 mm / 5.9 in (W) x 200 mm / 7.78 in (H)
Dimensions
Without thermometer
203 mm / 8 in (L) x 167 mm / 6.58in (W) x 200 mm / 7.87 in (H)
With thermometer
246 mm / 9.69 in (L) x 167 mm / 6.58in (W) x 232 mm / 9.13 in (H)Weight
Without thermometer
1500 g / 3.31 lb
With thermometer
1650 g / 3.64 lbCasing
PC and ABS
Warranty
2 years
NIBP (non-invasive blood pressure)
Measurement range
Adult
SYS 2 – 280 mmHg, DIA 10 – 220 mmHg, MAP 15 – 260 mmHg
Neonate
SYS 20 – 155 mmHg, DIA 5 – 110 mmHg, MAP 10 – 130 mmHgOverpressure protection
300 mmHg
SpO2
Measurement range
0 – 100%
Display range
0 – 99%
Accuracy
Adults ±2% (70 to 100%)
Children ±3% (70% to 100%)Pulse rate
Measurement range30 – 250 bpm
Pulse rate
Accuracy±1%
Predictive Thermometer – Filac™ 3000
Oral (Quick Mode)
non-fever temps: 3 - 5 seconds
fever temps: 8 - 10 secondsOral (Standard Mode)
6 - 10 seconds
Axillary Mode
8 – 12 seconds
Rectal Mode
10 – 14 seconds
Direct Mode (all sites)
60 – 120 seconds
Measurement accuracy
35.5°C - 42°C
Direct Mode (all sites): ±0.1°C (±0.2°F)
Standard Mode (all sites): ±0.1°C (±0.2°F)
Quick Mode (oral only): ± 0.3°C (±0.5°)
Ordering Information
Please note: This product is now discontinued.
This page is for product support/information only.
Art. No. | Description |
---|---|
1950-107 | ri-vital® NIBP, SpO2, bladderless cuffs for adults and large adults, finger sensor for adults |
1951-107 | ri-vital® NIBP, SpO2, bladderless cuffs for adults and large adults, finger sensor for adults, ear thermometer |
1953-107 | ri-vital® NIBP, SpO2, bladderless cuffs for adults and large adults, finger sensor for adults, oral/axillary thermometer |
1954-107 | ri-vital® NIBP, SpO2, bladderless cuffs for adults and large adults, finger sensor for adults, rectal thermometer |
1955-107 | ri-vital® NIBP, SpO2, bladderless cuffs for adults and large adults, finger sensor for adults |
1956-107 | ri-vital® NIBP, PEARL-SpO2, bladderless cuffs for adults and large adults, finger sensor for adults, oral/axillary thermometer |
1957-107 | ri-vital® NIBP, PEARL-SpO2, bladderless cuffs for adults and large adults, finger sensor for adults, oral/axillary thermometer |
1958-107 | ri-vital® NIBP, PEARL-SpO2, bladderless cuffs for adults and large adults, finger sensor for adults, rectal thermometer |
Accessories
SpO2 Sensors
Art. No. | Description |
---|---|
12663 | Wrap sensor for newborns |
12662 | Finger sensor for children |
12661 | Finger sensor for adults |
Blood Pressure Cuffs
Art. No. | Description |
---|---|
156 | Bladderless cuffs for neonates |
158 | Bladderless cuffs for infants |
154 | Bladderless cuffs for children |
160 | Bladderless cuffs for adults with thin arms |
150 | Bladderless cuffs for adults |
152 | Bladderless cuffs for large adults |
Other
Art. No. | Description | Pack-size |
---|---|---|
12667 | Extension module for infrared printer (holder and printer) | 1 |
12660 | Mobile stand with basket and holder for the mains adapter | 1 |
12664 | Extension cable for SpO2 length approx. 1.20 m (47.24 in) | 1 |
12668 | Rectal probe 2.7 m (106.3 in) | 1 |
12669 | Oral/axillary probe 2.7 m (106.3 in) | 1 |
12704 | Probe covers for ear thermometer | 100 pieces |
12688 | Probe covers for predictive thermometer | 500 pieces |
12685 | Paper roll for infrared printer | 20 pieces |
12687 | Infrared printer | 1 |
