XL Advantage Binocular Loupes

The XL Advantage Binocular Loupes are a magnification system offering 3.5x, 4.5x and 5.5x magnification.

XL Advantage Binocular Loupes with brow band

Table Of Contents

Excellent clarity for the experienced loupe users

XL Advantage Binocular Loupes details



Binocular Loupes Magnification Working distance Field of view
XL Advantage Binocular Loupes 3.5x 3.5 x 34 cm 5.5 cm
  3.5 x 42 cm 7.1 cm
  3.5 x 46 cm 7.9 cm
XL Advantage Binocular Loupes 4.5x 4.5 x 34 cm 4.6 cm
  4.5 x 42 cm 6.1 cm
  4.5 x 46 cm 6.9 cm
XL Advantage Binocular Loupes 5.5x 5.5 x 34 cm 3.5 cm
  5.5 x 42 cm 4.7 cm
  5.5 x 46 cm 5.3 cm

Image gallery

with-browband-480x

XL Advantage Binocular Loupes with brow band

xl-advantage-frame-480x

XL Advantage Binocular Loupes with spectacle frame

frame-480x

Spectacle frame without loupe

browband-01-x1000

Brow band without loupe

Features and benefits

  • Offers higher magnification for advanced surgical procedures
  • High prismatic quality ensures true image
  • Accurate colour reproduction excellent suitable for complex application
  • The XL precision lenses are treated with a non-reflecting protective coating to achieve an excellent image
  • Ideal for very highly precise procedures in all areas of application

Product details

XL Advantage Binocular Loupes


Ambient temperature + 10 °C to + 35 °C
Relative humidity 30 % to 90 % non-condensing
Air pressure 800 hPa - 1060 hPa
Shock (without packing) 10 g, duration 6 ms
Storage/ Transport temperature - 10 °C to + 55°C
Storage/ Transport relative humidity 10 % to 95 % non-condensing
Storage/ Transport Air pressure 700 hPa - 1060 hPa
Vibration, sinusoidal 10 Hz to 500 Hz: 0.5 g
Shock 30 g, duration 6 ms
Bump 10 g, duration 6 ms

Ordering information

XL Advantage Binocular Loupes

ART. NO. REGION DESCRIPTION
3980-635 EU XL Advantage 3.5X, at 34cm working distance
3981-635 EU XL Advantage 3.5X, at 42 cm working distance
3982-635 EU XL Advantage 3.5X, at 46 cm working distance
3980-645 EU XL Advantage 4.5X, at 34 cm working distance
3981-645 EU XL Advantage 4.5X, at 42 cm working distance

Accessories

ART. NO. REGION DESCRIPTION
12760 EU Protective caps for SuperVu Galilean
12761 EU Protective caps for SuperVu Galilean HiRes
12762 EU +1D close-up and distance cap for SuperVu Galilean
12763 EU +1D close-up and distance cap for SuperVu Galilean HiRes
12765 EU K-LED System with charger
12767 EU Protective caps (2 pcs.) for XL Advantage
12770 EU Spectacle frame, black w/o loupe
12771 EU Brow band w/o loupe
